Automatic Bottle Unscrambler Machine
Our Products Efficient Bottle Unscrambler Machine Manufacturer India
We are eminent name in the industry, delivering functionally updated array of Automatic Bottle Unscrambler used for Feeding of Bottles. The product is fully controlled electronically & provides perfect synchronization with the paking line as well as allows variation of the machine parameters. It is an automatic machine that does not require employees to manually sort the bottles. Bottles of different shapes and sizes can be unscrambled in the same machine without any change parts. This machine specially designed for high efficiency and high output with minimum chage over time. Automatic High Speed Bottle Unscambler is constructed of standard SS material to ensure maintenance free and noiseless operation.
This product is standard version that is exclusively designed to meet speed requirement of the client. It can workout for any shape like round, oval, square, etc and increase efficiency by boosting the capacity of your bottle feeding. Depending on container size and configuration, this model can reach speeds up to 300 containers per minute. This machine is ideal for packagers in the following industries: pharmaceuticals, Nutraceuticals, vitamins, and foods.
Applications of Automatic Bottle Unscrambler Machine
Pharmaceutical
FMCG
Cosmetics
Agriculture
Oil
Water Bottling Plants
Inquire Here
At Siddhivinayak Engineering, you can easily inquire about our products or services by filling out the inquiry form or contacting our team directly. Reach out today to get personalized support and detailed information tailored to your industrial packaging requirements.
Specification of Automatic Bottle Unscrambler Machine
| Model | SVHBU100 | SVHBU200 |
| Direction of Movement | Left To Right | Left To Right |
| Power Supply | 3.5kW,1 Phase 50 Hz AC supply + N +E | 3.5kW,1 Phase 50 Hz AC supply + N +E |
| MOC | S.S.304 | S.S.304 |
| Machine Dimension | 2800mm (L) x 1300mm (W) x 1900mm (H) | 3500mm (L) x 1500mm (W) x 1900mm (H) |
| Bottle Size | 25-90mm Dia. x 30-150 mm (H) | 50-90mm Dia. x 50-250 mm (H) |
| Bottle Storage Capacity | 600-800 Bottels (Dpends on Bottle Size) | 600-800 Bottels (Dpends on Bottle Size) |
| Change Part | Not required | Not required |
| Air Supply | 6-8 bar Continous Air Pressure with Air filter and Air regulator | 6-8 bar Continous Air Pressure with Air filter and Air regulator |
| Noise Level | 75-80 db | 75-80 db |
| Machine Weight (kg) | 850(Approx) | 600(Approx) |
| **If Optional Features Are Choosen,Above Data May Vary. | ||
Salient Features of Automatic Bottle Unscrambler Machine
- High Speed and Fully Automated
- Increases efficiency and productivity for production lines
- Fast adjustment reduces downtime and maximizes uptime
- Saves money through efficient use of personnel
- Low level alarm in Bulk hopper
- Contact parts are resistant to flaking, chipping, scuffing so will not cause any cosmetic damage to containers
- AC VFD for Elevator, feeder and oriented
- Speed – up to 300 containers per minute
- Compact in size and stable in working.
- S.S.304 construction i/c outer machine frame & all contact parts
- Smooth in feeding
- Easy to operate and vibration free ensure no inverted bottles go to the next machine
- Automatically correct position inverted bottles
- Running with high efficiency, no need workers watching
- Simple in structure. Easy to clean and maintain
- Suiitable for PET, HDPE bottles
Our Products
- Automatic Bottle Unscrambler Machine
- Bottle Washing Machine
- Filling Machine
- Capping Machine
- Labeling Machine
- Shrink Wrapping Machine
- Case Packing Machine
- Special Purpose Machine
Optional Features of Automatic Bottle Unscrambler Machine
- Low level alarm in storage of container
- Elevator speed control sensor
- Acrylic or Poly carbonate enclosure in frame
- Online ionized air cleaning
- Accumulation conveyor turn table of unscrambled containers
- Container counting
- Online container testing by leak test, weight test,etc.
Product Also Known As of Automatic Bottle Unscrambler Machine
- Automatic Bottle Unscrambler Machine
- Fully Automatic Bottle Unscrambler
- Automatic Unscrambler Machine
- Bottle Unscrambler Machine
- Automatic Bottle Unscrambler
- Bottle sorter machine
Machine Operation Process of Automatic Bottle Unscrambler Machine
-
Step 1
Empty bottles are loaded into the hopper.Hopper transfers bottles toward the rotary bottle feeding section by storage elevator belt convyor. -
Step 2
Bottle Seperator Belt will separate the bottle one by one and and feed to the Gripper belt.
-
Step 3
Bottles enter the gripper belt orientation section. Gripper belts with an orientation system orient bottles in the correct position and move to the exit belt station. -
Step 4
At exit belt station the stopper mechanism converts the bottle into a vertical position.Exit belt transfers vertically oriented bottles to the further conveyor line.
Video of Automatic Bottle Unscrambler Machine
Frequently Asked Questions
The product is fully controlled electronically & provides perfect synchronization with the filling line as well as allows variation of the machine parameters.
Automatic Bottle Unscrambler is designed to provide a loading solution for empty containers and delivers them to the downstream equipment conveyor in vertical condition lines in a controlled and repeatable manner. This model operates with great simplicity, efficiency, and minimal maintenance.An unscrambler is a machine designed to feed empty plastic bottles to a filling line on an ongoing, regular and automatic basis.
We strictly implement responsibility of the post,
1) When you confirm order,the design department will send the final design for your confirmation before production
2) The designer will follow the processing department to ensure each mechanical parts are processed correctly and timely
3) After all parts done,designer transfer responsibility to the Assembly Dept,which need to assemble the equipment on time
4) Responsibility transferred to Adjustment Dept with the assembled machine.Sales will check the progress and feedback to customer
5) After customer’s video checking/factory inspection,sales will arrange the delivery
6) If customer have problem during application,Sales will ask the After-sales Dept to solve it together
A bottle unscrambler is a machine used to feed bottles onto production lines in the bottling industries. Many designs are available, but their purpose is the same, feed bottles automatically at high speeds eliminating the expensive, inefficient manual labor of this process.
An automatic bottle unscrambler machine is suitable for the, healthcare, and food industries Pharmaceutical Syrup, Honey, Edible Oil, Lubricant Oil, Hair Oil, Shampoo, Cosmetics, Wine, Liquor, Beer.
Application of Automatic Bottle Unscrambler Machine
By Packaging Type
By Industries
By Application
Application of Automatic Bottle Unscrambler Machine
- By Packaging Type - PET, HDPE, Aluminium Can, Jar, Tin
- By Industries - Pharmaceutical , FMCG, Agriculture, Cosmetics, Oil, Distilleries
- By Application - Pharmaceutical Syrup, Honey, Edible Oil, Lubricant Oil, Hair Oil, Shampoo, Cosmetics, Wine, Liquor, Beer
Machine Operation Process of Automatic Bottle Unscrambler Machine
- Step 1- Empty bottles are loaded into the hopper.Hopper transfers bottles toward the rotary bottle feeding section by storage elevator belt convyor.
- Step 2- Bottle Seperator Belt will separate the bottle one by one and and feed to the Gripper belt.
- Step 3- Bottles enter the gripper belt orientation section. Gripper belts with an orientation system orient bottles in the correct position and move to the exit belt station.
- Step 4 - At exit belt station the stopper mechanism converts the bottle into a vertical position.Exit belt transfers vertically oriented bottles to the further conveyor line.
Video of Automatic Bottle Unscrambler Machine
Frequently Asked Questions
The product is fully controlled electronically & provides perfect synchronization with the filling line as well as allows variation of the machine parameters.
Automatic Bottle Unscrambler is designed to provide a loading solution for empty containers and delivers them to the downstream equipment conveyor in vertical condition lines in a controlled and repeatable manner. This model operates with great simplicity, efficiency, and minimal maintenance.An unscrambler is a machine designed to feed empty plastic bottles to a filling line on an ongoing, regular and automatic basis.
We strictly implement responsibility of the post,
1) When you confirm order,the design department will send the final design for your confirmation before production
2) The designer will follow the processing department to ensure each mechanical parts are processed correctly and timely
3) After all parts done,designer transfer responsibility to the Assembly Dept,which need to assemble the equipment on time
4) Responsibility transferred to Adjustment Dept with the assembled machine.Sales will check the progress and feedback to customer
5) After customer’s video checking/factory inspection,sales will arrange the delivery
6) If customer have problem during application,Sales will ask the After-sales Dept to solve it together
A bottle unscrambler is a machine used to feed bottles onto production lines in the bottling industries. Many designs are available, but their purpose is the same, feed bottles automatically at high speeds eliminating the expensive, inefficient manual labor of this process.
An automatic bottle unscrambler machine is suitable for the, healthcare, and food industries Pharmaceutical Syrup, Honey, Edible Oil, Lubricant Oil, Hair Oil, Shampoo, Cosmetics, Wine, Liquor, Beer.
Types of Technology
- Rotary Type – Uses a rotating bowl to orient and feed bottles efficiently.
- Linear / Conveyor Type – Bottles move along a conveyor system for sorting and alignment.
- Vacuum / Suction Type – Uses suction mechanisms to lift and orient bottles accurately.
- Pneumatic Type – Operates with compressed air for bottle movement and positioning.
- Servo Motor Controlled Type – Offers precise, programmable control for high-speed operations.
- Modular / Custom Type – Designed to handle specific bottle shapes, sizes, or production requirements.
Types of Packaging Material
- PET (Polyethylene Terephthalate) – Lightweight, durable, and widely used for beverages and liquids.
- HDPE (High-Density Polyethylene) – Common for chemicals, oils, and pharmaceutical liquids.
- Glass Bottles – Used in pharmaceuticals, cosmetics, and high-end beverages.
- Plastic Bottles (PP, PVC, etc.) – Suitable for cosmetic, food, and chemical packaging.
- Aluminum Bottles / Cans – Lightweight and corrosion-resistant, used for beverages and personal care products.
- Composite / Multi-Layer Bottles – Specialized packaging for sensitive liquids or chemicals.
Applications of Automatic Bottle Unscrambler Machine
- Pharmaceutical Industry – Sorting and aligning medicine bottles, syrups, and liquid containers.
- Food & Beverage Industry – Organizing bottles for juices, sauces, soft drinks, and edible oils.
- Cosmetic Industry – Handling shampoo, lotion, cream, and cosmetic product bottles.
- Chemical Industry – Feeding chemical bottles, cleaning agents, and laboratory containers.
- Nutraceuticals & Health Products – Aligning vitamin and supplement bottles.
- Beverage & Water Bottling Plants – Ensures smooth bottle flow in high-speed production lines.
